Switch|MIKROTIK|8x10Base-T / 100Base-TX / 1000Base-T|2xSFP+|CSS610-8P-2S+IN

192€

CSS610-8P-2S+IN

3 in stock
 Estimated Delivery: Up to 2-3 business days
 Delivery by courier: €5.90
 Free shipping on all orders over €500

Description

CSS610-8P-2S+IN is one of the most well-rounded switches on the market. It is a perfect fit for the most diverse setups: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features, and price offers unbelievable scalability potential.

There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at PoE-out.

This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields.

But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios – like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem. With our pricing, you can afford a switch on every floor!

Like every toolbox needs screwdrivers and pliers, every network can use a solid PoE switch.

SummaryMikrotik CSS610-8P-2S+IN. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Installed SFP+ modules quantity: 2. Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 48 - 57 V. Power over Ethernet (PoE). Rack mounting
Vendor Homepagehttps://mikrotik.com/product/css610_8p_2s_in#fndtn-downloads
Category CodeSWI
CnCode85176200
Unit Box Height0.25
Unit Box Length0.38
Unit Box Width0.065
Switch typeManaged
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity2
Networking standardsIEEE 802.3af/IEEE 802.3at
10G supportYes
Broadcast storm controlYes
VLAN supportYes
Switching capacity56
MAC address filteringYes
Rack mountingYes
Product colourWhite
Reset buttonYes
LED indicatorsYes
International Protection (IP) codeIP20
Operating system installedSwitchOS Lite
Processor modelMarvell 88E6193X
Flash memory0.064
FanlessYes
Mean time between failures (MTBF)200000
Power sourceAC/DC
Power supply includedYes
AC input voltage100 - 240
AC input frequency50 - 60
DC input voltage48 - 57
Input current2.2
Power consumption (max)162
Power over Ethernet (PoE)Yes

Description

8x10Base-T / 100Base-TX / 1000Base-T | 2xSFP+ | Dimensions 272 x 216 x 50 mm | Unit Net Weight 0.7 kg

Brand

MIKROTIK
