CASE PSU ATX 700W/GPA-700S CHIEFTEC

Name: CASE PSU ATX 700W/GPA-700S CHIEFTEC - IT-S.LV
SKU: 1207566
Price: 44.20 EUR
Availability: InStock

44,20€

GPA-700S

28 in stock

Estimated Delivery: Up to 2-3 business days
Delivery by courier: €5.90
Delivery by Omniva Parcel machine:€3.90
Free shipping on all orders over €500

Description	Chieftec iArena GPA-700s
Summary	Chieftec iArena GPA-700s. Total power: 700 W, AC input voltage: 200 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, Peripheral (Molex) power cable length: 500,650,800 mm. Purpose: PC/Server, Power supply unit (PSU) form factor: PS/2. Product colour: Silver, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: CB, CE, EAC
Vendor Homepage	https://www.chieftec.eu/products-detail/140/IARENA_SERIES/146/GPA-700S
Category Code	PSU
CnCode	85044095
Unit Box Height	0.09
Unit Box Length	0.22
Unit Box Width	0.155
Total power	700
AC input voltage	200 - 240
AC input frequency	47 - 63
Input current	5
Power factor	0.9
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	130
Combined power (+12V)	648
Combined power (+5V)	130
Combined power (-12V)	3.6
Combined power (+5Vsb)	12.5
Max output current (+3.3V)	22
Max output current (+12V)	50
Max output current (+5V)	22
Max output current (-12V)	0.3
Max output current (+5Vsb)	2.5
Efficiency	80
Power protection features	Over voltage/Overload/Short circuit/Under voltage
Motherboard power connector	20+4 pin ATX
Motherboard power cable length	500
Number of SATA power connectors	6
Peripheral (Molex) power connectors (4-pin)	2
Peripheral (Molex) power cable length	500/650/800
PCI Express power connectors (6+2 pin)	2
CPU power connector (4+4 pin)	Yes
CPU power cable length	550
ATX power connector (20+4 pin)	Yes
Floppy disk drive connector	Yes
